BFV-2EXC TYPE
BUTTERFLY VALVE,
DOUBLE EXCENTRIC,SHUT OFF
PN2.5 (0.63 MPa) / WAFER, LUG, FLANGE, BW
SPECIFICATIONS:
- DESIGN: EN593
- FACE TO FACE DIMENSION: ISO 5752
- END FLANGE DIMENSION: EN1092
- STD TEST: EN12266
- SHUT OFF: ANSI CLASS VI.
- SHELL TEST PRESSURE (Ps): 0.385 MPa
- SEAL TEST PRESSURE (Pn): 0.165 MPa
- TEMPERATURE RANGE: 0 to 150 º C
- SELF ADJUSTING STEM PACKING
- BLOW-OUT PROOF STEM DESIGN
- ISO 5211 MOUNTING PAD
- GEAR OPERATED / PNEUMATIC OPERATED
OPTIONS:
- SILICONE FREE / OIL & GREASE FREE
- APPLICATIOS: AS SHUTTING OFF OR FLOW CONTROLLING IN
CHIMNEYS AND DISCHARGING DUCTS - SERVICE: AIR, GAS, STEAM
